The AIRMIXS ZH-13D-08-10-10 is a high-performance, body-ported vacuum generator designed for localized vacuum creation in automated systems. By utilizing the venturi effect, this compact unit converts compressed air into a powerful vacuum source, making it essential for robotic pick-and-place applications, material handling, and leak testing.
This model features a 1.3 mm nozzle diameter and is equipped with integrated one-touch fittings for rapid, tool-free installation. The "Body Ported" (D-type) design is optimized for individual exhaust piping, allowing for precise control of air discharge in space-constrained environments. Its lightweight, resin-based body ensures minimal impact on the payload of moving robotic components.
Feature | Specification |
|---|
Model | ZH-13D-08-10-10 |
Type | Body Ported (Individual Exhaust) |
Nozzle Diameter | 1.3 mm |
Max. Vacuum Pressure | -88 kPa (Standard Type S) / -48 kPa (Large Flow Type L) |
Max. Suction Flow | Approx. 40 L/min (Standard Type S) |
Air Consumption | Approx. 84 L/min (Standard Type S) |
Standard Supply Pressure | 0.45 MPa (65 psi) |
Max. Operating Pressure | 0.6 MPa (87 psi) |
Supply Port (P) Size | Ø8 mm One-touch fitting |
Vacuum Port (V) Size | Ø10 mm One-touch fitting |
Exhaust Port (E) Size | Ø10 mm One-touch fitting |
Fluid | Compressed Air |
Operating Temperature | 5°C to 50°C |
