The ZH-07D-06-01-06 is a lightweight vacuum generator that utilizes the venturi principle to convert compressed air into a reliable vacuum source. With its specialized 0.7mm nozzle diameter, this unit is optimized for minimal air consumption while maintaining the necessary suction force for precision handling.
Constructed from a durable, impact-resistant composite resin, the unit includes integrated mounting holes for secure attachment to stationary frames or moving robotic end-effectors. The connection interface features high-speed blue One-Touch fittings for the pressure and exhaust ports, paired with a robust female threaded vacuum port for direct mounting to suction pads.
Feature | Specification |
|---|
Model | ZH-07D-06-01-06 |
Nozzle Diameter | 0.7 mm |
Body Style | T-Style (Body Ported) |
P Port (Supply) | 6 mm One-Touch Fitting |
V Port (Vacuum) | 1/8" Rc Female Thread |
E Port (Exhaust) | 6 mm One-Touch Fitting |
Max. Vacuum Pressure | -88 kPa |
Max. Suction Flow | 12 L/min (ANR) |
Air Consumption | 22 L/min (ANR) |
Operating Pressure | 0.2 ~ 0.5 MPa (29 ~ 72 PSI) |
Operating Temp. | 5°C to 50°C |
Material Type | High-Strength Composite Resin |
