The TKT-PC8-03 is a quick-connect straight male push-in pneumatic fitting engineered for reliable, tool-free tube assembly in automated fluid power systems and factory automation. Designed for quick setup, it features a one-touch connection system for standard 8 mm outer-diameter tubing and threads into $\frac{3}{8}$ " BSPT ports.
Equipped with an internal stainless steel lock-claw and a smooth release ring, this fitting ensures a firm grip and leak-free seal that resists pressure spikes and operational vibration without damaging the tube outer surface. The durable outer hexagonal body allows easy wrench access and efficient torque application during installation into valve blocks, cylinders, and air lines.
Feature | Specification |
|---|
Model Number | TKT-PC8-03 |
Fitting Type | Straight Male One-Touch / Push-In Fitting |
Connection Type | Tube to Male Thread |
Compatible Tubing O.D. | 8 mm |
Thread Size Designation | 03 (Equivalent to R $\frac{3}{8}$" / 3/8" BSPT Male Thread) |
Thread Type | Male BSPT (R / Tapered Thread) |
Compatible Tubing | Polyurethane (PU), Polyamide (Nylon/PA), Polyethylene (PE) |
Max. Operating Pressure | Up to 10 Bar (1.0 MPa / 150 PSI) |
Working Temperature Range | 0°C to +60°C |
Primary Media | Compressed Air, Vacuum |
