The TKT-PC8-01 is a high-performance straight male push-in connector designed to deliver fast, tool-free tube assembly in pneumatic control systems and automated machinery. Built for efficiency, this fitting enables instant push-to-connect operation for standard 8 mm outer-diameter tubing while securing directly into a $\frac{1}{8}$ " BSPT threaded port.
Featuring an internal lock-claw mechanism and an integrated release collar, it creates a secure, vibration-resistant, zero-leak seal that withstands daily mechanical strain without damaging the inserted tubing. The precision-machined external hex surface ensures effortless installation and tightening using standard wrenches.
Feature | Specification |
|---|
Model Number | TKT-PC8-01 |
Fitting Type | Straight Male One-Touch / Push-In Fitting |
Connection Type | Tube to Male Thread |
Compatible Tubing O.D. | 8 mm |
Thread Size Designation | 01 (Equivalent to R $\frac{1}{8}$" / 1/8" BSPT Male Thread) |
Thread Type | Male BSPT (R / Tapered Thread) |
Compatible Tubing | Polyurethane (PU), Polyamide (Nylon/PA), Polyethylene (PE) |
Max. Operating Pressure | Up to 10 Bar (1.0 MPa / 150 PSI) |
Working Temperature Range | 0°C to +60°C |
Primary Media | Compressed Air, Vacuum |
