The TKT-PC12-04 is a heavy-duty straight male push-in pneumatic fitting designed to adapt large 12 mm outer-diameter tubing to a broad $\frac{1}{2}$ " BSPT threaded port. Engineered for maximum airflow and rapid, tool-free installation, it optimizes throughput and simplifies maintenance across industrial fluid power and automation setups.
Equipped with a heavy-duty internal stainless steel lock-claw mechanism and an ergonomic release collar, this connector establishes a secure, vibration-resistant, zero-leak seal without compromising tube integrity. The integrated outer hexagonal collar allows for efficient torque wrenching during mounting into high-flow valve blocks, air distribution manifolds, and heavy pneumatic cylinders.
Feature | Specification |
|---|
Model Number | TKT-PC12-04 |
Fitting Type | Straight Male One-Touch / Push-In Fitting |
Connection Type | Tube to Male Thread |
Compatible Tubing O.D. | 12 mm |
Thread Size Designation | 04 (Equivalent to R \frac{1}{2}" / 1/2" BSPT Male Thread) |
Thread Type | Male BSPT (R / Tapered Thread) |
Compatible Tubing | Polyurethane (PU), Polyamide (Nylon/PA), Polyethylene (PE) |
Max. Operating Pressure | Up to 10 Bar (1.0 MPa / 150 PSI) |
Working Temperature Range | 0°C to +60°C |
Primary Media | Compressed Air, Vacuum |
