The TKT-PC12-03 is an industrial straight male push-in pneumatic fitting designed to seamlessly transition 12 mm outer-diameter tubing into a standard $\frac{3}{8}$ " BSPT threaded port. Engineered for high-flow capacity and tool-free tube connection, it facilitates rapid assembly, system modifications, and routine maintenance across factory automation lines and pneumatic circuits.
Featuring a robust internal stainless steel lock-claw mechanism paired with an ergonomic release collar, it forms a high-integrity, vibration-proof, leak-free seal without scoring or damaging the tube outer wall. The body incorporates a heavy-duty external hexagonal collar to ensure quick, wrench-tightened installation into pneumatic control manifolds, high-flow air cylinders, and valve blocks.
Feature | Specification |
|---|
Model Number | TKT-PC12-03 |
Fitting Type | Straight Male One-Touch / Push-In Fitting |
Connection Type | Tube to Male Thread |
Compatible Tubing O.D. | 12 mm |
Thread Size Designation | 03 (Equivalent to R $\frac{3}{8}$" / 3/8" BSPT Male Thread) |
Thread Type | Male BSPT (R / Tapered Thread) |
Compatible Tubing | Polyurethane (PU), Polyamide (Nylon/PA), Polyethylene (PE) |
Max. Operating Pressure | Up to 10 Bar (1.0 MPa / 150 PSI) |
Working Temperature Range | 0°C to +60°C |
Primary Media | Compressed Air, Vacuum |
