The TKT-PC12-02 is a heavy-duty straight male push-in pneumatic fitting designed to adapt 12 mm outer-diameter tubing directly to a standard $\frac{1}{4}$ " BSPT threaded port. Built for tool-free, instant tube connections, it ensures rapid installation and easy maintenance in high-flow pneumatic applications and factory automation lines.
Featuring an internal stainless steel lock-claw mechanism and an ergonomic release collar, it forms a high-integrity, vibration-proof, leak-free seal without scoring or damaging the tubing surface. The integrated external hexagonal collar allows effortless torque application with standard spanners, ensuring secure assembly into pneumatic cylinders, air distribution blocks, and valve manifolds.
Feature | Specification |
|---|
Model Number | TKT-PC12-02 |
Fitting Type | Straight Male One-Touch / Push-In Fitting |
Connection Type | Tube to Male Thread |
Compatible Tubing O.D. | 12 mm |
Thread Size Designation | 02 (Equivalent to R \frac{1}{4}" / 1/4" BSPT Male Thread) |
Thread Type | Male BSPT (R / Tapered Thread) |
Compatible Tubing | Polyurethane (PU), Polyamide (Nylon/PA), Polyethylene (PE) |
Max. Operating Pressure | Up to 10 Bar (1.0 MPa / 150 PSI) |
Working Temperature Range | 0°C to +60°C |
Primary Media | Compressed Air, Vacuum |
