The TKT-PC12-01 is a high-performance straight male push-in pneumatic fitting designed to adapt large 12 mm outer-diameter tubing into a compact $\frac{1}{8}$ " BSPT threaded port. Engineered for quick, tool-free tube assembly, it streamlines setup and maintenance in automated machinery and fluid power systems.
Featuring an internal lock-claw gripping mechanism paired with a smooth release ring, it provides a leak-free seal and dependable mechanical hold that withstands operational vibrations and pressure spikes without damaging the tube outer wall. Its outer body includes a heavy-duty hexagonal collar, allowing easy spanner wrenching during installation in tight or high-density pneumatic control manifolds.
Feature | Specification |
|---|
Model Number | TKT-PC12-01 |
Fitting Type | Straight Male One-Touch / Push-In Fitting |
Connection Type | Tube to Male Thread |
Compatible Tubing O.D. | 12 mm |
Thread Size Designation | 01 (Equivalent to R $\frac{1}{8}" / 1/8" BSPT Male Thread) |
Thread Type | Male BSPT (R / Tapered Thread) |
Compatible Tubing | Polyurethane (PU), Polyamide (Nylon/PA), Polyethylene (PE) |
Max. Operating Pressure | Up to 10 Bar (1.0 MPa / 150 PSI) |
Working Temperature Range | 0°C to +60°C |
Primary Media | Compressed Air, Vacuum |
