The TKT-PC10-04 is an industrial straight male push-in pneumatic fitting designed to adapt 10 mm outer-diameter tubing to a larger $\frac{1}{2}$ " BSPT threaded port. Engineered for high-flow capacity and tool-free tube connection, it facilitates rapid assembly and maintenance in factory automation and pneumatic supply networks.
Featuring a heavy-duty internal stainless steel lock-claw paired with an ergonomic release collar, it creates a secure, vibration-resistant, zero-leak seal without scoring the tubing. Its robust body is fitted with an integrated external hex collar, allowing smooth wrench tightening during installation into air manifolds, large-bore pneumatic cylinders, and main control valve blocks.
Feature | Specification |
|---|
Model Number | TKT-PC10-04 |
Fitting Type | Straight Male One-Touch / Push-In Fitting |
Connection Type | Tube to Male Thread |
Compatible Tubing O.D. | 10 mm |
Thread Size Designation | 04 (Equivalent to R $\frac{1}{2}" / 1/2" BSPT Male Thread) |
Thread Type | Male BSPT (R / Tapered Thread) |
Compatible Tubing | Polyurethane (PU), Polyamide (Nylon/PA), Polyethylene (PE) |
Max. Operating Pressure | Up to 10 Bar (1.0 MPa / 150 PSI) |
Working Temperature Range | 0°C to +60°C |
Primary Media | Compressed Air, Vacuum |
