The TKT-PC10-03 is an industrial-grade straight male push-in pneumatic fitting designed to connect 10 mm outer-diameter tubing directly to a standard $\frac{3}{8}$ " BSPT threaded port. Built for efficient, tool-free installation, it provides reliable performance across automated fluid power setups and industrial air supply systems.
Featuring an internal lock-claw gripping mechanism and a quick-release collar, it guarantees a high-integrity, vibration-proof, leak-free seal without causing surface wear or damage to the inserted tubing. The rugged hexagonal body structure provides convenient wrench access, enabling fast and torque-secure installation into pneumatic manifolds, air cylinders, and control valve assemblies.
Feature | Specification |
|---|
Model Number | TKT-PC10-03 |
Fitting Type | Straight Male One-Touch / Push-In Fitting |
Connection Type | Tube to Male Thread |
Compatible Tubing O.D. | 10 mm |
Thread Size Designation | 03 (Equivalent to R $\frac{3}{8}" / 3/8" BSPT Male Thread) |
Thread Type | Male BSPT (R / Tapered Thread) |
Compatible Tubing | Polyurethane (PU), Polyamide (Nylon/PA), Polyethylene (PE) |
Max. Operating Pressure | Up to 10 Bar (1.0 MPa / 150 PSI) |
Working Temperature Range | 0°C to +60°C |
Primary Media | Compressed Air, Vacuum |
