The TKT-PC10-02 is a durable straight male push-in connector designed to bridge 10 mm outer-diameter pneumatic tubing to a standard $\frac{1}{4}$ " BSPT threaded port. Engineered for high efficiency and tool-free tube assembly, this fitting ensures rapid setup and maintenance across industrial pneumatic systems.
Featuring an internal lock-claw system and a user-friendly release collar, it creates a secure, vibration-resistant, zero-leak connection that guards against accidental tube dislodgement. The integrated external hexagonal collar permits straightforward wrench-tightening during installation, ensuring a tight seal in pneumatic manifolds, solenoid valves, and automated machinery blocks.
Feature | Specification |
|---|
Model Number | TKT-PC10-02 |
Fitting Type | Straight Male One-Touch / Push-In Fitting |
Connection Type | Tube to Male Thread |
Compatible Tubing O.D. | 10 mm |
Thread Size Designation | 02 (Equivalent to R $\frac{1}{4}$" / 1/4" BSPT Male Thread) |
Thread Type | Male BSPT (R / Tapered Thread) |
Compatible Tubing | Polyurethane (PU), Polyamide (Nylon/PA), Polyethylene (PE) |
Max. Operating Pressure | Up to 10 Bar (1.0 MPa / 150 PSI) |
Working Temperature Range | 0°C to +60°C |
Primary Media | Compressed Air, Vacuum |
