The AIRMIXS SC125-CB is an extra-heavy-duty double-acting pneumatic tie-rod cylinder designed for high-capacity industrial automation, heavy press systems, material handling, and large-scale mechanical actuation. Featuring a large 125mm bore size and a factory-fitted Rear Clevis (CB) mounting bracket, this cylinder delivers exceptionally high pushing and pulling forces while allowing articulated swiveling and angular pivot motion for heavy linkage assemblies and tilting mechanisms.
Built with a high-strength anodized aluminum cylinder body, a heavy-duty chrome-plated steel piston rod, and dual adjustable end-of-stroke pneumatic cushioning, the SC125-CB effectively absorbs high kinetic energy to prevent end-cap shock and mechanical wear. Its rigid four-tie-rod frame provides maximum structural stability under severe dynamic thrusts while allowing straightforward installation of magnetic proximity switches without requiring line lubrication.
Technical Parameter | Specification |
|---|
Model / Part Number | SC125-CB Series |
Brand | AIRMIXS |
Cylinder Type | Standard Tie-Rod Pneumatic Cylinder |
Action Type | Double Acting |
Bore Size | 125 mm |
Mounting Style | Rear Clevis (CB Type Bracket) |
Cushioning | Adjustable Air Cushion at Both Ends |
Working Medium | Compressed Air (Filtered $\le$40 µm) |
Port Size | G 1/2" |
Operating Pressure Range | 0.1 to 1.0 MPa (1.0 to 10.0 bar / 14 to 145 PSI) |
Proof Pressure | 1.5 MPa (15 bar / 217 PSI) |
Piston Speed Range | 30 to 800 mm/sec |
Operating Temperature Range | -20°C to +80°C |
Lubrication | Not required |
