The AIRMIXS S3PP-06-G is a compact, high-efficiency 3-way direct-acting plastic solenoid valve designed for chemical media control, fluid redirection, and pneumatic signal switching. Built with a high-purity polypropylene (PP) body and 1/8" G-thread (parallel) ports, it provides exceptional chemical inertness against acids, alkalis, aggressive reagents, and pure water systems. Operating in a Normally Closed (NC) configuration, the valve requires zero minimum operating pressure differential, combining fast response times with low power consumption for sensitive laboratory, medical, and chemical handling applications.
| Parameter | Specification |
|---|
Model | S3PP-06-G |
Brand | AIRMIXS |
Valve Type | 3-Way / 2-Position, Direct-Acting |
Operation State | Normally Closed (NC) |
Port Size | 1/8" G-Thread (BSPP) |
Orifice Size | 1.5 mm |
Flow Coefficient (Cv) | 0.08 |
Operating Pressure | Air/Gas: 0 – 0.6 MPa (0 – 6 bar / 0 – 87 PSI)
Liquid: 0 – 0.4 MPa (0 – 4 bar / 0 – 58 PSI) |
Operating Temperature | 0°C to 60°C (32°F to 140°F) |
Fluid Compatibility | Acids, Alkalis, Pure Water, Corrosive Liquids, Filtered Air, Inert Gases |
Coil Voltage Options | DC 12V, DC 24V, AC 110V, AC 220V |
Power Consumption | DC: 2.0W / AC: 2.5VA |
Voltage Tolerance | ±10% |
Duty Cycle | 100% Continuous Duty |
Response Time | $\le 10\text{ ms}$ |
Seal Material | EPDM / Viton (FKM) |
