The AIRMIXS S3PL-M5 is an ultra-compact, corrosion-resistant 3-way direct-acting micro solenoid valve designed for high-precision fluid and pneumatic control in space-restricted environments. Operating in a Normally Closed (NC) configuration, the valve remains closed until electrically energized. Engineered with lightweight composite construction and M5 threaded ports, it provides rapid response times, low power consumption, and chemical resistance, making it ideal for medical diagnostics, analytical instruments, laboratory automation, and micro-fluidic control lines.
| Parameter | Specification |
|---|
Model | S3PL-M5 |
Brand | AIRMIXS |
Valve Type | 3-Way / 2-Position, Direct-Acting |
Operation State | Normally Closed (NC) |
Port Size | M5 x 0.8 Thread |
Orifice Size | 1.0 mm |
Flow Coefficient (Cv) | 0.05 |
Operating Pressure | Air/Gas: 0 – 0.7 MPa (0 – 7 bar / 0 – 101 PSI)
Liquid: 0 – 0.5 MPa (0 – 5 bar / 0 – 72.5 PSI) |
Operating Temperature | 0°C to 50°C (32°F to 122°F) |
Fluid Compatibility | Air, Neutral Gases, Water, Mild Chemicals, Reagents |
Coil Voltage Options | DC 12V, DC 24V |
Power Consumption | DC: 1.2W – 1.8W |
Voltage Tolerance | ±10% |
Duty Cycle | 100% Continuous Duty |
Response Time | \le 8\text{ ms} |
Seal Material | EPDM / Viton (FKM) |
