The AIRMIXS S3PL-08 is a corrosion-resistant 3-way direct-acting solenoid valve designed for high-flow pneumatic signal control, fluid redirection, and single-acting actuator driving in aggressive or sensitive fluid environments. Operating in a Normally Closed (NC) configuration, the valve remains closed until electrically energized. Engineered with a durable composite plastic body and 1/4" threaded ports, it provides excellent chemical compatibility, fast response times, and zero minimum pressure requirements, making it ideal for chemical dosing, water treatment, agricultural automation, and laboratory fluidic systems.
| Parameter | Specification |
|---|
Model | S3PL-08 |
Brand | AIRMIXS |
Valve Type | 3-Way / 2-Position, Direct-Acting |
Operation State | Normally Closed (NC) |
Port Size | 1/4" NPT / G |
Orifice Size | 2.0 mm |
Flow Coefficient (Cv) | 0.18 |
Operating Pressure | Air/Gas: 0 – 0.7 MPa (0 – 7 bar / 0 – 101 PSI)
Liquid: 0 – 0.5 MPa (0 – 5 bar / 0 – 72.5 PSI) |
Operating Temperature | 0°C to 50°C (32°F to 122°F) |
Fluid Compatibility | Air, Neutral Gases, Water, Corrosive Liquids, Reagents |
Coil Voltage Options | DC 12V, DC 24V, AC 110V, AC 220V |
Power Consumption | DC: 2.5W / AC: 3.5VA |
Voltage Tolerance | ±10% |
Duty Cycle | 100% Continuous Duty |
Response Time | $\le 12\text{ ms}$ |
Seal Material | EPDM / Viton (FKM) |
