The AIRMIXS S3D-08 is a compact, high-efficiency 3-way direct-acting solenoid valve designed for rapid pneumatic signal control, pressure release, and actuation of small single-acting cylinders. Operating in a Normally Closed (NC) configuration, the valve blocks flow until energized. Featuring 1/4" threaded connection ports, it delivers higher flow rates than micro-valve models while maintaining a compact footprint, making it ideal for packaging automation, pneumatic manifold panels, textile machinery, and pilot valve actuation.
| Parameter | Specification |
|---|
Model | S3D-08 |
Brand | AIRMIXS |
Valve Type | 3-Way / 2-Position, Direct-Acting |
Operation State | Normally Closed (NC) |
Port Size | 1/4" NPT / G |
Orifice Size | 2.0 mm |
Flow Coefficient (Cv) | 0.18 |
Operating Pressure | Air/Gas: 0 – 0.8 MPa (0 – 8 bar / 0 – 116 PSI) |
Operating Temperature | -5°C to 60°C (23°F to 140°F) |
Fluid Compatibility | Filtered Compressed Air, Inert Gases, Neutral Gaseous Media |
Coil Voltage Options | DC 12V, DC 24V, AC 110V, AC 220V |
Power Consumption | DC: 3.0W / AC: 4.0VA |
Voltage Tolerance | ±10% |
Duty Cycle | 100% Continuous Duty |
Response Time | $\le 15\text{ ms}$ |
Seal Material | NBR (Nitrile) |
