The AIRMIXS S3D-06 is a compact, high-precision 3-way direct-acting solenoid valve designed for fast, reliable pneumatic signal switching and small single-acting cylinder control. Operating in a Normally Closed (NC) configuration, the valve remains closed until energized. Featuring 1/8" threaded connection ports, it combines rapid response times, high flow efficiency, and a space-saving design, making it ideal for packaging machinery, pneumatic control manifolds, medical automation, and pilot control circuits.
| Parameter | Specification |
|---|
Model | S3D-06 |
Brand | AIRMIXS |
Valve Type | 3-Way / 2-Position, Direct-Acting |
Operation State | Normally Closed (NC) |
Port Size | 1/8" NPT / G |
Orifice Size | 1.5 mm |
Flow Coefficient (Cv) | 0.08 |
Operating Pressure | Air/Gas: 0 – 0.8 MPa (0 – 8 bar / 0 – 116 PSI) |
Operating Temperature | -5°C to 60°C (23°F to 140°F) |
Fluid Compatibility | Filtered Compressed Air, Inert Gases, Neutral Gaseous Media |
Coil Voltage Options | DC 12V, DC 24V, AC 110V, AC 220V |
Power Consumption | DC: 2.5W / AC: 3.0VA |
Voltage Tolerance | ±10% |
Duty Cycle | 100% Continuous Duty |
Response Time | $\le 12\text{ ms}$ |
Seal Material | NBR (Nitrile) |
