The PSL02 Plastic is a compact, high-efficiency porous plastic pneumatic silencer designed to damp exhaust air noise and filter particulate emissions from control valves, air cylinders, and manifold exhaust ports. Constructed from high-density porous polyethylene (PE) resin, it provides significant noise reduction while maintaining low backpressure resistance.
Featuring a 1/4" male threaded fitting, the PSL02 offers quick, tool-free installation into standard 1/4" exhaust ports. Its corrosion-resistant, lightweight, and non-clogging plastic body makes it an ideal solution for industrial automation equipment, packaging machinery, food processing setups, and cleanroom environments.
Specification | Technical Detail |
|---|
Model | PSL02 Plastic / PSL-02 |
Fitting Type | Pneumatic Plastic Silencer / Muffler |
Thread Size | 1/4" Male Thread (PT / BSPT / NPT options) |
Body Material | Porous Polyethylene (PE) Resin / PBT Plastic |
Filter Media | Sintered Porous Plastic (Foam Resin) |
Fluid Medium | Compressed Air, Exhaust Gas |
Operating Pressure Range | 0 to 10 bar (0 to 145 PSI / 1.0 MPa) |
Proof Pressure | 3.0 MPa (435 PSI) |
Operating Temperature | -10°C to +60°C (14°F to 140°F) |
Noise Reduction | Approx. 20 – 30 dB(A) |
