The PLG04-M5 is a ultra-compact plug-in male elbow fitting designed for precise, space-saving pneumatic setups. Featuring a 4mm plug-in stem on one side and an M5 metric male thread on the other, it plugs directly into existing 4mm push-in fitting ports or manifolds to create a compact right-angle connection to M5 threaded components.
Constructed with high-grade nickel-plated brass and equipped with a sealing O-ring on the M5 thread, the PLG04-M5 ensures an instant, leak-free connection without requiring additional sealant tape—ideal for compact valve blocks, miniature cylinders, and automated equipment.
Specification | Technical Detail |
|---|
Model | PLG04-M5 / PLG4-M5 |
Fitting Type | Plug-in Male Elbow (Stem to Thread) |
Plug/Stem Size | 4 mm Stem |
Thread Connection | M5 Metric Male Thread (M5 x 0.8) with O-ring |
Body Material | Nickel-Plated Brass & Durable PBT Composite |
Release Sleeve / Collet | POM Resin / Metal Collet |
Internal Sealing | Nitrile Rubber (NBR) / NBR O-Ring |
Fluid Medium | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 10 bar (0 to 145 PSI / 1.0 MPa) |
Operating Temperature | 0°C to +60°C (32°F to 140°F) |
Compatible Components | Standard 4mm Push-in Ports / M5 Ported Valves & Cylinders |
