The AIRMIXS PL06-04 is a robust 90-degree swivel male elbow designed for high-performance pneumatic systems. It facilitates a rapid, tool-free connection between 6mm O.D. tubing and a large 1/2" BSPT female port.
The swivel mechanism allows the PBT body to rotate 360 degrees after the threaded base is installed, providing unmatched flexibility for tube routing in cramped industrial environments. Combining high-strength thermoplastic with nickel-plated brass components, this fitting is engineered for longevity and reliable performance under standard industrial pressures. It is a preferred choice for automotive manufacturing, pneumatic control panels, and heavy-duty machinery.
Feature | Specification |
|---|
Model Number | PL06-04 |
Tube Outer Diameter (O.D.) | 6 mm |
Thread Size | 1/2" BSPT (R1/2) |
Shape | 90° Right Angle Elbow |
Fluid Type | Compressed Air, Vacuum, Water (no freezing) |
Operating Pressure | 0 to 1.0 MPa (0 to 150 psi) |
Negative Pressure | -100 kPa (-29.5 in Hg) |
Proof Pressure | 1.5 MPa (217 psi) |
Temperature Range | 0 to 60°C (32 to 140°F) |
