The AIRMIXS PL06-02 is a versatile 90-degree swivel male elbow designed for complex pneumatic routing. It allows for a rapid, tool-free connection between 6mm O.D. tubing and a 1/4" BSPT female port.
The swivel mechanism enables the thermoplastic body to rotate 360 degrees after the threaded base has been secured, allowing for precise tube alignment in tight industrial spaces. Constructed with PBT and nickel-plated brass, this fitting is engineered to withstand standard industrial pressures while maintaining an airtight seal. This component is widely used in automotive assembly, packaging systems, and automated production lines.
Feature | Specification |
|---|
Model Number | PL06-02 |
Tube Outer Diameter (O.D.) | 6 mm |
Thread Size | 1/4" BSPT (R1/4) |
Shape | 90° Right Angle Elbow |
Fluid Type | Compressed Air, Vacuum, Water (no freezing) |
Operating Pressure | 0 to 1.0 MPa (0 to 150 psi) |
Negative Pressure | -100 kPa (-29.5 in Hg) |
Proof Pressure | 1.5 MPa (217 psi) |
Temperature Range | 0 to 60°C (32 to 140°F) |
