The AIRMIXS PCF10-01 Female Straight Connector is a heavy-duty push-to-connect fitting engineered to connect a 10mm pneumatic tube to a 1/8" male threaded fitting or manifold port.
Ideal for industrial automation, high-flow air distribution circuits, and control systems, it features a fast, tool-free push-in connection on one side and a precise 1/8" female thread on the other. Its internal locking claw securely retains 10mm tubing under high pressure while permitting quick, hassle-free disconnection via the release collar.
Specification | Value / Technical Detail |
|---|
Model Code | PCF10-01 |
Fitting Type | Female Straight Connector |
Tube Connection Outer Diameter (OD) | 10 mm |
Thread Connection | 1/8" BSPT / PT Female Thread |
Compatible Media | Compressed Air, Vacuum |
Operating Pressure Range | 0 – 1.0 MPa (0 – 150 PSI / 0 – 10 bar) |
Max / Proof Pressure | 1.32 MPa to 1.5 MPa |
Vacuum / Negative Pressure | -100 kPa (-29.5 inHg / -750 mmHg) |
Operating Temperature | 0°C to 60°C (32°F to 140°F) |
Applicable Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
