The AIRMIXS PCF 08-04 is an industrial-grade, straight female push-to-connect fitting engineered to connect metric pneumatic lines directly to a male threaded connection. As shown in AIRMIXS PCF 08-04.jpg, this precision component features a solid, full nickel-plated brass body and a high-strength composite release collar, establishing a secure, leak-free union for 8mm outer diameter (OD) tubing.
Its stepped, straight profile efficiently transitions from an 8mm tube line to a wide, robust 1/2" female threaded base, making it ideal for high-flow manifold setups, valve connections, and mainline pneumatic distributions. Built to deliver long-term structural integrity in high-duty automated lines, packaging machinery, and manufacturing systems, it optimizes flow path efficiency with zero hassle.
Specification | Technical Data |
|---|
Model Number | PCF 08-04 |
Fitting Type | Straight Female Connector |
Port A (Tube Connection) | 8mm Tube OD |
Port B (Thread Connection) | 1/2" PT / BSPT / G (Female Thread) |
Body Material | Nickel-Plated Brass |
Release Collar Material | Industrial Polymer Composite (White) |
Applicable Tubing Material | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
Working Fluid | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 150 PSI (0 to 1.0 MPa) |
Negative Pressure Range | -29.5 in Hg (-100 kPa) |
Operating Temperature Range | 32°F to 140°F / 0°C to 60°C |
