The AIRMIXS PCF06-02 Female Straight Connector is a high-efficiency push-to-connect fitting designed to transition a 6mm pneumatic tube directly to a 1/4" male threaded fitting or port.
Ideal for automated machinery, air distribution manifolds, and pneumatic control panels, it provides a reliable, tool-free push-in connection on one side and a robust 1/4" female thread on the other. Its precision internal gripping mechanism holds tubing firmly under pressure while allowing effortless release when required.
Specification | Value / Technical Detail |
|---|
Model Code | PCF06-02 |
Fitting Type | Female Straight Connector |
Tube Connection Outer Diameter (OD) | 6 mm |
Thread Connection | 1/4" BSPT / PT Female Thread |
Compatible Media | Compressed Air, Vacuum |
Operating Pressure Range | 0 – 1.0 MPa (0 – 150 PSI / 0 – 10 bar) |
Max / Proof Pressure | 1.32 MPa to 1.5 MPa |
Vacuum / Negative Pressure | -100 kPa (-29.5 inHg / -750 mmHg) |
Operating Temperature | 0°C to 60°C (32°F to 140°F) |
Applicable Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
