The AIRMIXS PCF04-M5 Female Straight Fitting is a compact push-to-connect pneumatic adapter designed for quick and reliable connections between 4mm outer-diameter tubing and male M5 threaded equipment or sensor ports.
Engineered for compact industrial automation assemblies, this straight fitting features a spring-loaded release collar for instant, tool-free tubing installation and extraction. The internal hexagonal body profile allows easy tightening in tight manifold configurations, delivering a secure, leak-free seal across compressed air applications.
Specification | Value / Technical Detail |
|---|
Model Code | PCF04-M5 (PCF4-M5) |
Fitting Type | Female Straight Push-In Connector |
Tube Connection Outer Diameter (OD) | 4 mm |
Thread Connection | M5 x 0.8 Female Metric Thread |
Thread Seal Style | Integrated Sealing Gasket / O-ring |
Compatible Media | Compressed Air, Vacuum |
Operating Pressure Range | 0 – 1.0 MPa (0 – 150 PSI / 0 – 10 bar) |
Max / Proof Pressure | 1.32 MPa (190 PSI) |
Operating Temperature | 0°C to 60°C (32°F to 140°F) |
Applicable Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
