The PC1/2-1/2 is a heavy-duty straight male push-to-connect pneumatic fitting engineered for quick, secure, and tool-free air line connections. Designed with a 1/2" push-in tube connection at one end and a 1/2" male thread on the opposite end, it provides high flow capacity and a leak-resistant seal ideal for industrial automation, pneumatic cylinders, air lines, and heavy equipment. The release collar allows fast tube insertion and effortless disconnection without damaging the tubing.
Technical Specification | Parameter / Value |
|---|
Model Number | PC1/2-1/2 |
Fitting Type | Straight Male Connector / Push-in Fitting |
Tube OD (A Port) | 1/2 Inch (12.7 mm) |
Thread Size (B Port) | 1/2 Inch NPT / Male Thread |
Fluid Media | Compressed Air, Vacuum |
Working Pressure Range | 0 to 150 PSI (0 to 1.0 MPa / 10 bar) |
Proof Pressure | Up to 435 PSI (3.0 MPa) |
Operating Temperature | 0°C to 60°C (32°F to 140°F) |
Applicable Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
Sealing Method | Pre-coated Thread Sealant / O-ring Seal |
