The PC12-03 Male Straight Connector is an industrial quick-connect pneumatic fitting designed to transition a 12mm outer diameter (OD) tube directly to a 3/8" BSPT (R 3/8) female threaded port. Built for reliability and fast assembly, it features an effortless one-touch push-in release collar for secure tubing retention and easy disengagement. Equipped with an external hex profile for straightforward mounting using standard wrenches, this component provides a leak-tight connection in automated equipment, heavy-duty pneumatic systems, and compressed air distribution circuits.
Specification | Value |
|---|
Model | PC12-03 (or PC12-3/8) |
Fitting Type | Male Straight Connector / Push-In Threaded Fitting |
Applicable Tube Outer Diameter (OD) | 12mm |
Thread Size & Type | 3/8" BSPT (R 3/8 Male Tapered Thread) |
Fluid Medium | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 1.0 MPa (0 to 10 bar / ~145 PSI) |
Negative Pressure / Vacuum | -100 kPa (-29.5 inHg / -750 mmHg) |
Operating Temperature | 0°C to 60°C (32°F to 140°F) |
Compatible Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
Connection Method | One-Touch Push-In (Tube Side) / Threaded (Port Side) |
