The PB10-04 Male Branch Tee Fitting is designed to connect two 10mm OD tubes to a single 1/2" female threaded port at a 90^\circ angle. Featuring a one-touch push-to-connect mechanism, it enables fast, tool-free tube assembly and disassembly in pneumatic systems.
Built with a durable thermoplastic (PBT) body and a nickel-plated brass thread section pre-treated with thread sealant, this connector delivers reliable, leak-proof performance across air and vacuum lines. The body can rotate 360^\circ after installation to facilitate easy routing in compact spaces.
Specification | Technical Detail |
|---|
Model | PB10-04 |
Fitting Type | Male Branch Tee (Push-In / One-Touch) |
Tubing Outer Diameter (OD) | 10 mm |
Male Thread Size | R 1/2" (1/2" BSPT / PT Taper Thread) |
Fluid Compatibility | Compressed Air, Vacuum |
Working Pressure Range | 0 \text{ to } 0.9 \text{ MPa} (0 \text{ to } 130 \text{ PSI}) |
Max Pressure Rating | 1.32 \text{ MPa} (190 \text{ PSI}) |
Operating Temperature | 0^\circ\text{C} \text{ to } 60^\circ\text{C} (32^\circ\text{F} \text{ to } 140^\circ\text{F}) |
Compatible Tubing Material | Polyurethane (PU), Polyethylene (PE), Nylon (PA) |
Body Material | PBT Plastic + Nickel-Plated Brass |
Thread Seal Treatment | Pre-applied PTFE Thread Sealant |
