The AIRMIXS MU-MIDI-40N-1/2" Air Preparation Unit is a high-flow, heavy-duty 3-in-1 FRL modular system designed for main air supply lines, high-demand pneumatic equipment, and automated production machinery. Featuring G 1/2" port connections and an expanded MIDI body configuration, this unit combines three vital air treatment functions into one coordinated assembly: stripping out liquid condensate and particulate contaminants, regulating operating pressure with high stability, and delivering a fine oil mist to continuously lubricate internal cylinder seals and control valves.
Constructed with a rugged die-cast aluminum housing and impact-resistant polycarbonate bowls encased in heavy protective steel guards, it provides long-term reliability under severe industrial working conditions. The pressure regulator features an ergonomic push-to-lock detent adjustment knob to prevent setting drift caused by machinery vibration, while the oil lubricator includes a transparent sight dome for precise, proportional drip rate tuning.
Feature / Specification | Detail |
|---|
Brand | AIRMIXS |
Model | MU-MIDI-40N-1/2" |
Series / Size | MIDI Series |
Component Type | Heavy-Duty FRL Combination Unit (Filter + Regulator + Lubricator) |
Port Size | G 1/2" (BSP) / NPT 1/2" |
Gauge Port Size | G 1/4" |
Filter Micron Rating | 40 µm (Standard) / 5 µm (Optional) |
Max Supply Pressure | 1.6 MPa (16 Bar / 232 PSI) |
Proof Pressure | 2.0 MPa (20 Bar / 290 PSI) |
Pressure Regulation Range | 0.05 – 1.2 MPa (0.5 – 12 Bar / 7 – 175 PSI) |
Nominal Flow Rate | ~3,200 – 3,600 L/min |
Drain Type | Manual / Semi-Automatic Drain |
Recommended Lubricant | ISO VG32 / Turbine No. 1 Oil |
Body Material | Heavy-Duty Die-Cast Aluminum |
Bowl Material | Polycarbonate with Protective Steel Guard |
Working Temperature Range | -10°C to +60°C (14°F to 140°F) |
Fluid Medium | Compressed Air / Inert Gases |
