The MPV16 is a heavy-duty, large-capacity all-metal hand valve fitting designed to connect two 16mm outer diameter pneumatic tubes, providing direct manual control over compressed air flow. Constructed entirely from nickel-plated brass, it offers high pressure endurance, chemical stability, and robust durability in demanding industrial environments.
Featuring dual push-to-connect metal release sleeves and an integrated manual flow control mechanism, the MPV16 guarantees a secure, leak-proof seal with fast, tool-free installation for main pneumatic distribution lines and automated equipment.
Specification | Technical Detail |
|---|
Model | MPV16 / MPV-16 |
Fitting Type | Hand Valve / In-line Shut-off Valve (Tube-to-Tube Union) |
Tubing Outer Diameter (OD) | 16 mm (Port 1) x 16 mm (Port 2) |
Body Material | Nickel-Plated Brass |
Release Sleeve Material | Metal (Nickel-Plated Brass) |
Internal Sealing | Nitrile Rubber (NBR) |
Fluid Medium | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 10 bar (0 to 145 PSI / 1.0 MPa) |
Operating Temperature | 0°C to +60°C (32°F to 140°F) |
Compatible Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
