The MPV14 is an all-metal hand shut-off valve fitting designed to connect two 14mm outer diameter pneumatic tubes, allowing manual control over airflow within a system. Built with high-grade nickel-plated brass, it offers superior resistance to mechanical wear, high pressures, and harsh industrial environments compared to composite or plastic alternatives.
Featuring dual push-to-connect ports with metal release sleeves and an integrated manual shut-off control, the MPV14 enables fast, tool-free tube installations and reliable air supply control for maintenance, automation, and compressed air lines.
Specification | Technical Detail |
|---|
Model | MPV14 / MPV-14 |
Fitting Type | Hand Valve / Shuttle Valve (Tube-to-Tube Union) |
Tubing Outer Diameter (OD) | 14 mm (Port 1) x 14 mm (Port 2) |
Body Material | Nickel-Plated Brass |
Release Sleeve Material | Metal (Nickel-Plated Brass) |
Internal Sealing | Nitrile Rubber (NBR) |
Fluid Medium | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 10 bar (0 to 145 PSI / 1.0 MPa) |
Operating Temperature | 0°C to +60°C (32°F to 140°F) |
Compatible Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
