The MPE16 is a high-capacity, heavy-duty all-metal 90-degree union elbow fitting designed to connect two 16mm outer diameter pneumatic tubes at a right angle. Built with full nickel-plated brass, it provides maximum mechanical strength, high temperature stability, and outstanding resistance to corrosion and harsh industrial environments compared to composite or plastic alternatives.
Featuring dual push-to-connect ports with ergonomic metal release sleeves, the MPE16 ensures a firm, leak-proof connection with fast, tool-free hose insertion and removal for heavy-duty pneumatic supply lines and automated machinery.
Specification | Technical Detail |
|---|
Model | MPE16 / MPE-16 |
Fitting Type | 90° Union Elbow (Tube-to-Tube) |
Tubing Outer Diameter (OD) | 16 mm (Port 1) x 16 mm (Port 2) |
Body Material | Nickel-Plated Brass |
Release Sleeve Material | Metal (Nickel-Plated Brass) |
Internal Sealing | Nitrile Rubber (NBR) |
Fluid Medium | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 10 bar (0 to 145 PSI / 1.0 MPa) |
Operating Temperature | -10°C to +60°C (14°F to 140°F) |
Compatible Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
