The MPE12 is a heavy-duty, all-metal 90-degree union elbow fitting designed to connect two 12mm outer diameter pneumatic tubes at a right angle. Built with high-grade nickel-plated brass, it provides exceptional durability, mechanical strength, and superior resistance to high temperatures and harsh industrial conditions compared to standard plastic fittings.
Featuring dual push-to-connect ports with metal release sleeves, the MPE12 ensures a secure, leak-proof hold and quick, tool-free tube installations in high-flow pneumatic and automation lines.
Specification | Technical Detail |
|---|
Model | MPE12 / MPE-12 |
Fitting Type | 90° Union Elbow (Tube-to-Tube) |
Tubing Outer Diameter (OD) | 12 mm (Port 1) x 12 mm (Port 2) |
Body Material | Nickel-Plated Brass |
Release Sleeve Material | Metal (Nickel-Plated Brass) |
Internal Sealing | Nitrile Rubber (NBR) |
Fluid Medium | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 10 bar (0 to 145 PSI / 1.0 MPa) |
Operating Temperature | -10°C to +60°C (14°F to 140°F) |
Compatible Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
