The MPE08 is a heavy-duty, all-metal 90-degree union elbow fitting engineered for connecting two 8mm outer diameter pneumatic tubes around sharp corners or tight layouts. Manufactured from full nickel-plated brass, it offers superior corrosion resistance, high pressure endurance, and exceptional mechanical strength compared to plastic-body fittings.
Equipped with dual metal push-to-connect release sleeves, the MPE08 guarantees a tight, leak-free seal and fast, tool-free tube attachment for compressed air lines and industrial automation machinery.
Specification | Technical Detail |
|---|
Model | MPE08 / MPE-8 |
Fitting Type | 90° Union Elbow (Tube-to-Tube) |
Tubing Outer Diameter (OD) | 8 mm (Port 1) x 8 mm (Port 2) |
Body Material | Nickel-Plated Brass |
Release Sleeve Material | Metal (Nickel-Plated Brass) |
Internal Sealing | Nitrile Rubber (NBR) |
Fluid Medium | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 10 bar (0 to 145 PSI / 1.0 MPa) |
Operating Temperature | -10°C to +60°C (14°F to 140°F) |
Compatible Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
