The MPE06 is an all-metal 90-degree union elbow fitting designed to connect two 6mm outer diameter pneumatic tubes at a right angle. Built with robust nickel-plated brass, it offers superior resistance to mechanical wear, high temperatures, and harsh chemical environments compared to standard plastic-composite fittings.
Featuring dual push-to-connect ports with metal release sleeves, the MPE06 provides a secure, leak-free seal and fast, tool-free tube installations for industrial automation and compressed air lines.
Specification | Technical Detail |
|---|
Model | MPE06 / MPE-6 |
Fitting Type | 90° Union Elbow (Tube-to-Tube) |
Tubing Outer Diameter (OD) | 6 mm (Port 1) x 6 mm (Port 2) |
Body Material | Nickel-Plated Brass |
Release Sleeve Material | Metal (Nickel-Plated Brass) |
Internal Sealing | Nitrile Rubber (NBR) |
Fluid Medium | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 10 bar (0 to 145 PSI / 1.0 MPa) |
Operating Temperature | -10°C to +60°C (14°F to 140°F) |
Compatible Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
