The AIRMIXS J-B012 3/8" is a compact, high-pressure mini ball valve featuring a Male-to-Male (M x M) thread configuration. Precision-machined from high-grade AISI 304 stainless steel, it is engineered for tight spaces in pneumatic control lines, water manifolds, and fluid systems. Its smooth 90-degree lever operation allows fast, positive manual shut-off, while the solid stainless steel construction provides superior resistance to corrosion, high pressure, and temperature extremes.
Feature / Specification | Detail |
|---|
Model Code | J-B012-3/8 (A304-03-MM) |
Valve Type | Mini Ball Valve (Quarter-Turn Manual) |
Body Material | AISI 304 Stainless Steel |
Thread Connection | 3/8" Male to 3/8" Male (NPT / BSP) |
Flow Port | Standard / Reduced Port |
Seal Material | PTFE (Teflon) |
Operating Pressure | Up to 1000 PSI (WOG / 6.9 MPa) |
Operating Temperature | -20°C to +150°C |
Fluid Medium | Compressed Air, Water, Oil, Inert Gases |
