The AIRMIXS J-B012 1/2" is a heavy-duty, compact mini ball valve featuring a Male-to-Male (M x M) thread connection. Manufactured from corrosion-resistant AISI 304 stainless steel, it is designed for reliable flow isolation and control in compressed air, water, oil, and fluid processing lines. Its dual male thread configuration allows direct coupling into female-threaded equipment or manifolds without requiring extra pipe nipples, saving space and assembly time in tight control cabinets or plumbing setups.
Feature / Specification | Detail |
|---|
Model Code | J-B012-1/2 (A304-04-MM) |
Valve Type | Mini Ball Valve (Quarter-Turn Manual) |
Body Material | AISI 304 Stainless Steel |
Thread Connection | 1/2" Male to 1/2" Male (NPT / BSP) |
Flow Port | Standard / Reduced Port |
Seal Material | PTFE (Teflon) |
Operating Pressure | Up to 1000 PSI (WOG / 6.9 MPa) |
Operating Temperature | -20°C to +150°C |
Fluid Medium | Compressed Air, Water, Oil, Inert Gases |
