The AIRMIXS FRC-3/4 MIDI is a heavy-duty 3-in-1 air preparation service unit (FRL) that integrates particulate filtration, precise pressure regulation, and micro-fog oil mist lubrication into a high-capacity assembly. Designed in a MIDI body size with larger 3/4" port connections, this combination unit extracts moisture condensate and solid contaminants down to 40 µm, provides steady downstream line pressure via a locking adjustment knob, and automatically feeds a controlled aerosol oil mist to protect heavy-duty pneumatic actuators, cylinders, and air tools from internal friction and corrosion.
Parameter | Specification |
|---|
Brand | AIRMIXS |
Model / Part Number | FRC-3/4 MIDI |
Port Size | 3/4" NPT / G-Thread |
Body Size | MIDI (55 mm Grid Dimension) |
Unit Type | Integrated Filter-Regulator + Lubricator (FRL Combo) |
Filter Rating | 40 µm (Standard) |
Lubricator Type | Proportional Oil Mist |
Pressure Regulation Range | 0.5 bar – 12 bar (7.25 psi – 174 psi) |
Max. Operating Pressure | 16 bar (232 psi) |
Standard Nominal Flow Rate | 2,600 L/min |
Temperature Range | -10°C to +60°C |
Drain Type | Manual / Semi-Automatic Drain |
Actuator Lock | Rotary Knob with Lock Ring |
Bowl Guard | High-Strength Polycarbonate Bowls with Metal Guards |
Recommended Lubricant Oil | ISO VG32 pneumatic tool oil |
Compatible Media | Compressed Air, Neutral Industrial Gases |
