The BL6-04 is a robust 90° male elbow compression fitting built entirely from nickel-plated brass. It connects a 6mm outer diameter pneumatic tube to a large 1/2" male thread port. Designed for high pressure stability and harsh industrial environments, its compression lock-nut design guarantees a leak-proof, vibration-resistant seal for compressed air, vacuum, and fluid systems.
Feature / Specification | Detail |
|---|
Model Code | BL6-04 |
Fitting Type | 90° Male Elbow Compression / Rapid Fitting |
Tube Outer Diameter (O.D.) | 6 mm |
Thread Connection | R 1/2" (BSPT) / PT 1/2" Male Thread |
Body Material | Nickel-Plated Brass |
Fluid Medium | Compressed Air, Vacuum, Water |
Operating Pressure | 0 to 1.5 MPa (0 – 15 bar / 215 PSI) |
Operating Temperature | -20°C to +80°C |
Compatible Tubing | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
