The AIRMIXS PU Series 24VDC Replacement Solenoid Valve Coil is designed for reliable electromagnetic actuation in automated pneumatic and fluid control systems. Built specifically for PU series solenoid valves, this low-voltage DC coil delivers consistent magnetic power, swift valve switching, and low power dissipation for long operational lifespans. Its fully encapsulated construction protects internal windings from ambient environmental hazards, while the standard DIN terminal connections allow for straightforward plug-and-play installation and easy maintenance in low-voltage DC industrial setups.
Parameter | Specification |
|---|
Brand | AIRMIXS |
Compatible Valve Series | PU Series (PU220-02, PU220-03, PU220-04, PU220-06, PU220-08) |
Operating Voltage | 24VDC |
Voltage Tolerance | ±10% |
Power Consumption | 4.8 W to 6.5 W |
Electrical Connection | DIN 43650 Form A / Form B Plug-in Terminal |
Protection Class | IP65 (with properly fitted DIN connector gasket) |
Duty Cycle | 100% ED (Continuous Duty) |
Insulation Class | Class H / Class F |
Ambient Temperature Range | -20°C to +60°C |
Response Time | ≤ 15 ms |
