The AIRMIXS 2W Series 110VAC Replacement Solenoid Valve Coil provides stable, high-efficiency electromagnetic actuation for general-purpose 2-way direct-acting solenoid valves. Designed for full compatibility with 2W series valve assemblies, this coil features a fully encapsulated, heat-resistant housing that protects internal copper windings from environmental moisture, dust, and continuous mechanical stress. Operating on standard 110VAC line power, it ensures rapid response times and consistent holding force, with standard plug-in DIN terminal connectors for simple field maintenance without disconnecting pipe lines.
Parameter | Specification |
|---|
Brand | AIRMIXS |
Compatible Valve Series | 2W Series (2W025-08, 2W160-15, 2W200-20, 2W250-25, 2W350-35, 2W400-40, 2W500-50) |
Operating Voltage | 110VAC |
Voltage Tolerance | ±10% |
Power Consumption | 15 VA to 22 VA (50/60 Hz) |
Electrical Connection | DIN 43650 Form A / Form B Terminal Plug |
Protection Class | IP65 (with properly installed DIN connector gasket) |
Duty Cycle | 100% ED (Continuous Duty) |
Insulation Class | Class H / Class F |
Ambient Temperature Range | -20°C to +60°C |
Response Time | ≤ 25 ms |
