The 600PF 3/4" is a heavy-duty, high-flow pneumatic quick-connect plug (male adapter) designed for high-demand compressed air systems and industrial pneumatic tools. Featuring a 1/2" body profile with a 3/4" female thread port, it plugs directly into 600SF series sockets or standard Japanese (Nitto-style) high-flow couplers. Built from heat-treated chrome-plated steel or brass, it provides maximum airflow, exceptional wear resistance, and a leak-tight connection under continuous air pressure.
Feature / Specification | Detail |
|---|
Model Code | 600PF (3/4") |
Coupler Component | Quick Connect Plug / Nipple (Male Adapter) |
Interchange Standard | Japanese / Nitto Hi-Cupla Profile (600 Series) |
Body Flow Size | 1/2" High Flow |
Thread Connection | 3/4" Female Thread (RC 3/4" / BSPT / NPT) |
Material Finish | Chrome-Plated Hardened Steel / Brass / Stainless Steel |
Valve Mechanism | Valveless / Open Flow Design (Plug Side) |
Operating Pressure | 0 to 1.5 MPa (0 – 15 bar / 215 PSI) |
Temperature Range | -20°C to +80°C (-4°F to +176°F) |
Compatible Media | Compressed Air, Inert Gases |
